Incoloy 601 pipe for high - temp scenarios

The Incoloy 601 steel pipe boasts remarkable mechanical properties, including excellent tensile strength and resistance to stress corrosion cracking. Its unique composition allows it to maintain structural integrity even in the most challenging conditions, such as those found in furnace applications and heat treatment processes. This makes it a reliable choice for manufacturers looking to enhance the durability and longevity of their equipment.
One of the standout features of Incoloy 601 is its ability to resist oxidation and carburization at elevated temperatures, which is crucial for maintaining performance in high-temperature environments. This resistance not only extends the lifespan of the pipe but also reduces maintenance costs and downtime, providing significant savings for businesses.

    specification

    Product Name Incoloy 601 Pipe
    Standard ASTM,JIS,DIN,GB,AISI,DIN,EN

    Outer Diameter

    Round Pipe

    4mm-200mm
    Square Pipe 10*10mm-100*100mm
    Rectangular Pipe 10*20mm-50*100mm
    Wall Thickness 0.6mm-6.0mm
    Length 1-6 meters, Length can be customized
    Error ±1%
    Certification ISO 9001 ,CE,API
    Surface treatment Black, Bright Polished, Rough Turning, Matt Surface Treatment, No.4, BA, etc.
    Production Technology Hot Rolling, Cold Rolling
    Country of origin China
    Main Applications Oil and gas industry, chemical industry, power industry, building and construction, automotive industry, aerospace, machinery manufacturing
    Package Bundling, wooden box packaging, pallet packaging, plastic film packaging, anti-rust oil coating, container transportation
    Payment Term TT, LC,Cash, Paypal, DP, DA,Western Union or Others.
    After-sales service 1. Quality assurance period 2. Return and exchange policy 3. Delivery and acceptance assistance 4. Customer feedback collection

    Product Display

    • product-description1
    • product-description2
    • product-description3

    Chemical Composition

    C Al Si S Cr Mn Fe Ni Cu
    0.1 max 1.0-1.7 0.5 max 0.015 max 21.0-25.0 1.0 max Remainder 58.0-63.0 1.0 max

    Mechanical Properties

    Tensile Strength (ksi) 0.2% Yield Strength (ksi) Elongation% in 2 inches

    80

    30

    30

    Physical Performance

      Units Temperature in°C

    Density

    8.11 g/cm³

    Room

    Specific Heat

    0.107 Kcal/kg.C

    20°

    Melting Range

    1360-1411°C

    -

    Modulus of Elasticity

    206.5 KN/mm²

    20°

    Electrical Resistivity

    118 µΩ.cm

    20°

    Coefficient of Expansion

    13.75 µm/m °C

    20 - 100°

    Thermal Conductivity

    11.2 w/m-° K

    20°
