1100 Aluminum Bar for Industrial Applications

The 1100 aluminum alloy is composed of 99.0% aluminum, making it one of the purest forms of aluminum available. This purity not only enhances its malleability but also ensures that it can be easily formed, welded, and machined to fit your specific project requirements. With a low density and high strength-to-weight ratio, this aluminum bar is ideal for applications where weight savings are crucial without compromising structural integrity.
In addition to its physical properties, the 1100 Aluminum Bar is also environmentally friendly, as aluminum is 100% recyclable without losing its quality. This makes it a sustainable choice for businesses looking to reduce their carbon footprint while still achieving high-performance results.

product details

specification

Diameter	5-650mm or customized	Length	100-2000mm or customized
Certificate	ISO.SGS.BV
Standard	JIS, AiSi, ASTM, GB, DIN, EN etc.
Trademark	1000 series:1050 1060 1070 1100 1200 1235 etc.3000 series:3003 3004 3005 3104 3105 3A21 etc.5000 series:5005 5052 5083 5086 5154 5182 5251 5754 5A05 etc.6000 series:6061 6063 6082 6A02 etc.7000 series:7050 7475 7075 etc.8000 series:8A06 8011 8090 etc.
Surface	Coating, embossing, drawing, polishing, anodizing, etc.
OEM service	Drilling holes, cutting special sizes, making flat surfaces, surface treatment, etc.
Delivery time	7-15 working days after receiving 30% deposit
Application	Construction, shipbuilding, decoration, industry, manufacturing, machinery, hardware and other fields
Sample	free samples
Package	Bundling, plastic bags, films, wooden pallets standard seaworthy export packaging or as per customer requirements

Product Display

Chemical Composition

Alloy

Others:

Each

Others:

Total

Al: Min.

3A21

0.60

0.70

0.20

1.0-1.6

0.05

0.15

0.1-0.2

Margin

Mechanical Properties

Tensile Strength (MPa)	Yield Strength (MPa)	Hardness HB	Elongation Rate (%)
89.6	34	23	15-28

Physical Performance

Density	Melting Point	Modulus of Elasticity	Thermal Conductivity
2.71 Kg/m³	643-675.2 °C	68.9 GPa	222 W/m.K

Annealing State

Brand	Annealing State
1xxx: 1050, 1050A, 1060, 1100	O, H12, H14, H16, H18, H22, H24, H26, H28, H111
3xxx: 3003, 3004, 3005, 3105	O, H12, H14, H16, H18, H22, H24, H26, H28, H111
5xxx: 5005, 5052, 5754, 5083, 5086, 5182, 5049, 5251, 5454	O, H22, H24, H26, H28, H32, H34, H36, H38, H111
6xxx: 6061, 6082	T4, T6, T451, T651
2xxx: 2024	T3, T351, T4
7xxx: 7075	T6, T651

Scope of Application

Aluminum Uses And Application Area
Food Packaging	Beverage can ends, cans, bottle caps, etc.
Building	Curtain walls, cladding, suspended ceilings, thermal insulation, venetian blinds, etc.
Transportation	Auto parts, passenger car bodies, aviation ships and air cargo containers.
Electronic Equipment	Electrical appliances, communication equipment,PCPlate drilling guide, lighting and heat dissipation materials, etc.
Consumer Goods	Umbrellas, cooking utensils, sports equipment, etc
Other	Military, color coated aluminum plate
